Autonics Proximity Sensor, 8mm Sensing, 25mm Flat, PNP, NO, 3 Wire, 10-30 VDC
- Brand: AUTONICS
- Product Code: PFI25-8DP
- Availability: 2-3 Days
$45.00
Download Spec sheet in PDF| Model | PS12-4DN PS12-4DP PS12-4DN2 PS12-4DNU PS12-4DPU PS12-4DN2U |
PSN17-5DN PSN17-5DP PSN17-5DN2 PSN17-5DP2 PSN17-5DNU PSN17-5DN2U PSN17-5DPU PSN17-5DP2U PSN17-5DN-F |
PSN17-8DN PSN17-8DN-F PSN17-8DP PSN17-8DP-F PSN17-8DN2 PSN17-8DN2-F PSN17-8DP2 PSN17-8DP2-F PSN17-8DNU PSN17-8DNU-F PSN17-8DPU PSN17-8DPU-F PSN17-8DN2U PSN17-8DN2U-F PSN17-8DP2U PSN17-8DP2U-F |
PSN25-5DN PSN25-5DP PSN25-5DN2 PSN25-5DP2 |
PSN30-10DN PSN30-10DP PSN30-10DN2 PSN30-10DP2 |
PSN30-15DN PSN30-15DP PSN30-15DN2 PSN30-15DP2 |
PSN40-20DN PSN40-20DP PSN40-20DN2 PSN40-20DP2 |
PS50-30DN PS50-30DP PS50-30DN2 PS50-30DP2 |
|
| Sensing distance | 4mm | 5mm | 8mm | 5mm | 10mm | 15mm | 20mm | 30mm | |
| Hysteresis | Max. 10% of sensing distance | ||||||||
| Standard sensing target | 12x12x1mm (Iron) | 18x18x1mm (Iron) | 25x25x1mm (lron) |
30x30x1mm (Iron) | 45x45x1mm (Iron) | 60x60x1mm (Iron) | 90x90x1 mm (Iron) | ||
| Setting distance | 0 to 2.8mm |
0 to 3.5mm |
0 to 5mm |
0 to 3.5mm | 0 to 7mm |
0 to 10.5mm | 0 to 14mm |
0 to 21mm | |
| Power supply (Operation voltage) | 12-24VDC (10-30VDC) |
||||||||
| Current consumption | Max. 10mA | ||||||||
| Response frequency†1 | 500Hz | 700Hz | 200Hz | 300Hz | 250Hz | 200Hz | 100Hz | 50Hz | |
| Residual voltage | Max. 1.5V | ||||||||
| Affection by Temp. | Max. ±10% for sensing distance at ambient temperature 20°C | ||||||||
| Control output | Max. 200mA | ||||||||
| Insulation resistance | Min. 50MΩ(at 500VDC megger) | ||||||||
| Dielectric strength | 1500VAC 50/60Hz for Iminute | ||||||||
| Vibration | 1mm amplitude at frequency of 10 to 55Hz(for 1 min.) in each of X, Y, Z directions for 2 hours | ||||||||
| Shock | 500m/s2(approx. 50G) in each of X1 Y, Z directions for 3 times | ||||||||
| Indicator | Operation indicator(red LED) | ||||||||
| Environment | Ambient temperature | -25 to 70°C, storage : -30 to 80°C | |||||||
| Ambient humidity | 35 to 95%RH, storage :35 to 95%RH | ||||||||
| Protection circuit | Surge protection circuit, overcurrent protection circuit, reverse polarity protection circuit | ||||||||
| Protection | IP67(IEC standard) | ||||||||
| Cable | Ø4, 3-wire, 2m | Ø5,3-wire, 2m | |||||||
| (AWG22, Core diameter: 0.08mm, Number of cores: 60, Insulator out diameter: Ø1.25) | |||||||||
| Meterial | Case: Heat-resistant ABS, Standard cable(Black): Polyvinyl chloride(PVC). | ||||||||
| Approval | CE | ||||||||
| Unit weight | Approx. 62g | Approx. 71g | Approx. 70g | Approx. 111g | Approx. 185g | Approx. 220g | |||
| Document download |  |
||||||||
†The case color of PNP output type is changed from orange to gray.
